Back to Pallet Transporters Platform Transporter
Platform-Style Bed
The Platform Transporter is the ideal solution for easily moving heavy carts and dollies, driving underneath to lift them and maneuver them around a facility.
The Platform Transporter is the ideal solution for easily moving heavy carts and dollies, driving underneath to lift them and maneuver them around a facility.
Platform Transporter
Specs & Sizing
Features
Video Library
Platform Transporter
Easily move and position loads up to hundreds of thousands of pounds with the Platform Transporter - the ideal solution for easily moving heavy loads in manufacturing facilities. All Platform Transporters are customizable to fit your operation - configurable with multi-directional drives for crab steering and zero degree turning, safety scanners, and AGV drive systems.
View More Photos
Looking for a customized solution? We do that too.
Request a Free Consultation
Product
Measurement Units
|
Model No.
Model No.
|
Capacity (lbs)
Capacity (kgs)
|
Length (in)
Length (mm)
|
Width (in)
Width (mm)
|
Height (in)
Height (mm)
|
Stroke (in)
Stroke (mm)
|
Battery (volts/amps)
Battery (volts/amps)
|
Recharge Time 50-95% (hrs)
Recharge Time 50-95% (hrs)
|
Number of Drives
Number of Drives
|
Speed max (FpM)
Speed max (MpM)
|
Battery Life (ft)
Battery Life (m)
|
|---|---|---|---|---|---|---|---|---|---|---|
|
Model No.
Model No.
HED031-0020
HED031-0020
|
Capacity (lbs)
Capacity (kgs)
44,000
20,000
|
Length (in)
Length (mm)
157 11/16
4,005
|
Width (in)
Width (mm)
50 3/8
1,280
|
Height (in)
Height (mm)
43 5/16
1,100
|
Stroke
Stroke
3 1/8
80
|
Battery (volts/amps)
Battery (volts/amps)
48V , 320 A
48V , 320 A
|
Recharge Time (hrs)
Recharge Time (hrs)
3
3
|
Number of Drives
Number of Drives
1
1
|
Speed Max (FpM)
Speed Max (MpM)
148
45
|
Battery Life (ft)
Battery Life (m)
16,400
5,000
|
|
Model No.
Model No.
HED031-0030
HED031-0030
|
Capacity (lbs)
Capacity (kgs)
66,000
30,000
|
Length (in)
Length (mm)
177 3/8
4,505
|
Width (in)
Width (mm)
61
1,550
|
Height (in)
Height (mm)
46 7/16
1,180
|
Stroke
Stroke
3 15/16
100
|
Battery (volts/amps)
Battery (volts/amps)
48V , 420 A
48V , 420 A
|
Recharge Time (hrs)
Recharge Time (hrs)
6
6
|
Number of Drives
Number of Drives
1
1
|
Speed Max (FpM)
Speed Max (MpM)
98
30
|
Battery Life (ft)
Battery Life (m)
14,750
4,500
|
|
Model No.
Model No.
HED031-0040
HED031-0040
|
Capacity (lbs)
Capacity (kgs)
88,000
40,000
|
Length (in)
Length (mm)
197 1/16
5,005
|
Width (in)
Width (mm)
61
1,550
|
Height (in)
Height (mm)
46 7/16
1,180
|
Stroke
Stroke
3 15/16
100
|
Battery (volts/amps)
Battery (volts/amps)
48V , 420 A
48V , 420 A
|
Recharge Time (hrs)
Recharge Time (hrs)
6
6
|
Number of Drives
Number of Drives
1
1
|
Speed Max (FpM)
Speed Max (MpM)
98
30
|
Battery Life (ft)
Battery Life (m)
13,100
4,000
|
|
Model No.
Model No.
HED031-0060
HED031-0060
|
Capacity (lbs)
Capacity (kgs)
132,500
60,000
|
Length (in)
Length (mm)
216 3/4
5,505
|
Width (in)
Width (mm)
61
1,550
|
Height (in)
Height (mm)
46 7/16
1,180
|
Stroke
Stroke
3 15/16
100
|
Battery (volts/amps)
Battery (volts/amps)
48V , 420 A
48V , 420 A
|
Recharge Time (hrs)
Recharge Time (hrs)
6
6
|
Number of Drives
Number of Drives
1
1
|
Speed Max (FpM)
Speed Max (MpM)
98
30
|
Battery Life (ft)
Battery Life (m)
11,500
3,500
|
|
Model No.
Model No.
HED031-0080
HED031-0080
|
Capacity (lbs)
Capacity (kgs)
176,500
80,000
|
Length (in)
Length (mm)
240 3/8
6,105
|
Width (in)
Width (mm)
66 9/16
1,690
|
Height (in)
Height (mm)
51 3/16
1,300
|
Stroke
Stroke
3 15/16
100
|
Battery (volts/amps)
Battery (volts/amps)
48V , 600 A
48V , 600 A
|
Recharge Time (hrs)
Recharge Time (hrs)
6
6
|
Number of Drives
Number of Drives
1
1
|
Speed Max (FpM)
Speed Max (MpM)
98
30
|
Battery Life (ft)
Battery Life (m)
9,850
3,000
|
|
Model No.
Model No.
HED031-0120
HED031-0120
|
Capacity (lbs)
Capacity (kgs)
264,500
120,000
|
Length (in)
Length (mm)
240 3/8
6,105
|
Width (in)
Width (mm)
86 5/8
2,200
|
Height (in)
Height (mm)
51 3/16
1,300
|
Stroke
Stroke
3 15/16
100
|
Battery (volts/amps)
Battery (volts/amps)
48V , 600 A
48V , 600 A
|
Recharge Time (hrs)
Recharge Time (hrs)
6
6
|
Number of Drives
Number of Drives
1
1
|
Speed Max (FpM)
Speed Max (MpM)
69
21
|
Battery Life (ft)
Battery Life (m)
6,550
2,000
|
Discover the benefits
of battery powered.
of battery powered.
Request a Quote
Increase
in Safety
in Safety
The Platform Transporter features a flat bed that slides underneath heavy loads and uses hydraulic lifts to pick them up for movement. Instead of using overhead cranes to dangerously move loads, Platform Transporters keep operators at a safe distance from the move.
All
Electric
Electric
No fumes, gases, or odd smells will be put into the air of your facility. Our electric transporters are emission free and operate clean and green. The whole transporter recharges within just a few short hours, allowing your facility to stay on top of its game and minimize downtime.
Customization
Options
Options
We like to take care of our customers, as their success fuels our own. Need a customer charging solution? We’ll take care of it. Special safety features? We can do that. Specific requirements that need to be met for your facility? We’ll work with you to meet those standards. We’re no stranger to customization - it’s what we do best.
Platform Transporter Video Library
FREQUENT QUESTIONS
What’s the difference between a Flatbed Transporter and a Pallet Transporter?
The Pallet Transporter is a low-profile loading bed, with a controllable unit at the end. Our Flatbed Transporters are an all-in-one design and offer a higher load height than other transporters.
I don’t see the right size of the Platform Transporter that I’m looking for.
In addition to our readily available sizes, we offer custom engineering and development to come up with solutions unique to each customer. If you’re looking for specific sizing or if you need help finding the right solution for you, click the “Contact Us” button for different ways you can reach us.
What type of battery options are available on Hedin USA products?
We offer our products with the choice of either dry and wet cell batteries. Please contact our sales engineering team to determine which battery type is best suited for your application.
