Quick Mold & Die Transporter
Drastically reduce down time & eliminate safety concerns in your molding or stamping line with Quick-Change Mold & Die Systems from Hedin USA. The Quick-Change Mold & Die Transporter is designed to maximize safety for operators and efficiency when changing Molds or Dies on your molding or stamping line. The Quick-Change system utilizes a roller bed with loading arms, enabling the transporter to extract the mold onto one roller bed, then haul it away for storage, cleaning, or maintenance.
View More Photos
Looking for a customized solution? We do that too.
Request a Free Consultation
Product
Measurement Units
|
Model No.
Model No.
|
Capacity (lbs)
Capacity (kgs)
|
Length (in)
Length (mm)
|
Width (in)
Width (mm)
|
Height (in)
Height (mm)
|
Stroke (in)
Stroke (mm)
|
Battery (volts/amps)
Battery (volts/amps)
|
Recharge Time 50-95% (hrs)
Recharge Time 50-95% (hrs)
|
Number of Drives
Number of Drives
|
Speed max (FpM)
Speed max (MpM)
|
Battery Life (ft)
Battery Life (m)
|
|---|---|---|---|---|---|---|---|---|---|---|
|
Model No.
Model No.
HED040-0006
HED040-0006
|
Capacity (lbs)
Capacity (kgs)
13,000
6,000
|
Length (in)
Length (mm)
165 3/8
4,200
|
Width (in)
Width (mm)
90 9/16
2,300
|
Height (in)
Height (mm)
104 5/16
2,650
|
Stroke
Stroke
41 3/4
1060
|
Battery (volts/amps)
Battery (volts/amps)
48V 320 A
48V 320 A
|
Recharge Time (hrs)
Recharge Time (hrs)
3
3
|
Number of Drives
Number of Drives
1
1
|
Speed Max (FpM)
Speed Max (MpM)
150
45
|
Battery Life (ft)
Battery Life (m)
13,100
4,000
|
|
Model No.
Model No.
HED040-00012
HED040-00012
|
Capacity (lbs)
Capacity (kgs)
26,500
12,000
|
Length (in)
Length (mm)
165 3/8
4,200
|
Width (in)
Width (mm)
90 9/16
2,300
|
Height (in)
Height (mm)
104 5/16
2,650
|
Stroke
Stroke
41 3/4
1060
|
Battery (volts/amps)
Battery (volts/amps)
48V 420 A
48V 420 A
|
Recharge Time (hrs)
Recharge Time (hrs)
6
6
|
Number of Drives
Number of Drives
1
1
|
Speed Max (FpM)
Speed Max (MpM)
100
30
|
Battery Life (ft)
Battery Life (m)
13,100
4,000
|
|
Model No.
Model No.
HED040-0020
HED040-0020
|
Capacity (lbs)
Capacity (kgs)
44,000
20,000
|
Length (in)
Length (mm)
177 3/16
4,500
|
Width (in)
Width (mm)
98 7/16
2,500
|
Height (in)
Height (mm)
114 3/16
2,900
|
Stroke
Stroke
41 3/4
1060
|
Battery (volts/amps)
Battery (volts/amps)
48V 420 A
48V 420 A
|
Recharge Time (hrs)
Recharge Time (hrs)
6
6
|
Number of Drives
Number of Drives
1
1
|
Speed Max (FpM)
Speed Max (MpM)
100
30
|
Battery Life (ft)
Battery Life (m)
9,800
3,000
|
|
Model No.
Model No.
HED040-0010
HED040-0010
|
Capacity (lbs)
Capacity (kgs)
22,000
10,000
|
Length (in)
Length (mm)
141 3/4
3,600
|
Width (in)
Width (mm)
55 1/8
1,400
|
Height (in)
Height (mm)
82 11/16
2,100
|
Stroke
Stroke
31 7/8
810
|
Battery (volts/amps)
Battery (volts/amps)
48V 320 A
48V 320 A
|
Recharge Time (hrs)
Recharge Time (hrs)
3
3
|
Number of Drives
Number of Drives
1
1
|
Speed Max (FpM)
Speed Max (MpM)
150
45
|
Battery Life (ft)
Battery Life (m)
13,100
4,000
|
Discover the benefits
of battery powered.
of battery powered.
Request a Quote
Reduce
Down Time
Down Time
The Mold & Die Transporter eliminates overhead cranes and unsafe moves, presenting a safe solution to quickly and efficiently changing out molds on molding or stamping lines.
Customization
Options
Options
We like to take care of our customers, as their success fuels our own. Need a customer charging solution? We’ll take care of it. Special safety features? We can do that. Specific requirements that need to be met for your facility? We’ll work with you to meet those standards. We’re no stranger to customization - it’s what we do best.
Roller
Bed
Bed
We utilize a roller bed on the Transporter, enabling it to extract the mold onto the bed and then haul it away for storage, cleaning, or maintenance.
Die & Mold Transporter Video Library
FREQUENT QUESTIONS
I don’t see the right size or product that I’m looking for.
In addition to our readily available sizes, we offer custom engineering and development to come up with solutions unique to each customer. If you’re looking for specific sizing or if you need help finding the right solution for you, click the “Contact Us” button for different ways you can reach us.
What safety features are offered on your equipment?
Safety features vary from product to product, but we are proud to say that safety is our number one priority for our products. We offer a range of safety equipment on our machinery to ensure that the equipment can be operated safely and efficiently.
Where are your products manufactured?
We are proud to say that all of our products are manufactured and designed in the United States of America, in partnership with Hedin Lagan based in Sweden. Hedin USA is headquartered in St. Louis, Missouri, and our products are manufactured at our facility in Decatur, Illinois.
